TruLink Standard Flange Clamp Connect

Trulink Flange

TruLink Standard Flange Clamp Connect

$239.26$1,095.39

In stock

$239.26$1,095.39

Clear
View cart

Description

TruLink Standard Flange Clamp Connect

THE NEXT GENERATION OF ALUMINUM PIPING SYSTEMS

Completely designed, engineered, and manufactured by AST, TruLink combines the proven reliability, safety, and installation ease of the past with cutting edge material, engineering, and manufacturing technology.

TruLink is manufactured from high quality, marine-grade aluminum to provide the highest level of protection against corrosion. Our smooth bore, extruded tubing is manufactured in the USA and ensures that the media traveling through a system encounters very little turbulence, while enabling high flow rates with minimal pressure losses compared to conventional steel systems.

By utilizing aluminum, we guarantee a 30-55% weight reduction over traditional systems -making TruLink easy to install and modify. Also, aluminum is the best material choice for corrosion and rust resistance, so the system will remain operating at maximum efficiency for the duration of use.

WHAT SETS TRULINK APART FROM TRADITIONAL PIPING SYSTEMS?

  • All Aluminum System
  • Compatible with Common Groove Technology
  • 2x Deeper Tubing Engagements
  • Seven industry leading patented technologies
  • Leak Free Guarantee @ 300 psi, 300°F
  • Zero Rust & Corrosion
  • Food Grade Compliant
  • 30-55% Lighter Weight than Traditional Systems
  • Long Radius Elbows, Threaded Elbows
  • Fitting Size Clearly Identified on Casting
  • Automated Assembly in the USA
  • Installation ready upon delivery
  • Lifetime warranty covering all piping and fittings
Size TruLink Part Number
73mm Tube To ANSI 2.5″, 150 Flange w/ Gasket and Bolts TC4-73
90mm Tube To ANSI 3″, 150 Flange w/ Gasket and Bolts TC4-90
115mm Tube To ANSI 4″, 150 Flange w/ Gasket and Bolts TC4-115
168mm Tube To ANSI 6″, 150 Flange w/ Gasket and Bolts TC4-168
 220mm Tube To ANSI 8″, 150 Flange w/ Gasket and Bolts TC4-220



Additional information

Weight N/A
Diameter

, , , ,

Series

ANSI

2.5", 3", 4", 6", 8"
