Ball Valves-Tube to Male NPT Threads
$55.69 – $83.55
Use on drops with a manifold for easy point of use shut-off. Connects to 20 or 25 mm Infinity piping with a reducing threaded male output.
- Description
- Additional information
Description
Infinity™ Ball Valves-Tube to Male NPT Threads
Use on drops with a manifold for easy point of use shut-off. Connects to 20 or 25 mm Infinity piping with a reducing threaded male output.
Infinity™ Ball Valves-Tube to Male NPT Threads Part Numbers
| PART NUMBER | D | F (NPTF) | D.N. | A | B | C | E | L | CH1 | CH2 | G | H |
| 90721-20-08 | 20 | 1/2 | 15 | 17 | 31,5 | 29.3 | 34.5 | 100.8 | 32 | 30 | 88 | 42 |
| 90721-25-12 | 25 | 3/4 | 20 | 17,5 | 38,5 | 30.8 | 42.5 | 119.3 | 41 | 35 | 106 | 47,5 |
